TORNADO RMD
Medium duty rotary cutters
35-80 HP (26-60 KW)
540 rpm - Cat. 1
- Cutting heights: from 1″ to 9 1/4″
- Replaceable skids
- Highly engineered & rugged gearbox
- Heavy duty shielded PTO shaft with slip clutch safety (1 3/8″ ASAE cat. 4)
- 3 point linkage, cat. 1
- Floating top link
- Exceptionally heavy duty 1/2″x4″ spring steel blades
- 2″ cutting capcity
- High blade tip speed
- Laminated tail wheel with tapered roller bearings (4″x8″x15″)
- Oval heavy duty stump jumper standard
- Heavy duty reinforced 8 gauge deck
- Front & rear protective chain shields standard
| Model | HP | Working width | Overall width | Weight lbs | Ship lbs | Rotor rpm | Blades tip speed (ft/min) | # Blades & sizes | Cutting height | Laminated wheel size | Driveline 1 3/8" |
|---|---|---|---|---|---|---|---|---|---|---|---|
RMD-360 | 35-80 | 60" | 68" | 695 | 695 | 855 | 13,189 | (2) 1/2"x4" | 1" to 9 1/4" | 4"x8"x15" | ASAE cat. 4 slip clutch |
RMD-372 | 40-80 | 72" | 80" | 785 | 785 | 855 | 15,748 | (2) 1/2"x4" | 1" to 9 1/4" | 4"x8"x15" | ASAE cat. 4 slip clutch |
WARNING: Because of possible injury from thrown objects, all rotary cutters are potenitally dangerous.
Any rotary cutter intedended for use along roadways or other locations where people may be present must be used with safety shielding in place.
WARNING: When using a quick hitch on a PTO driven implement, always ensure there is proper overlap prior to use. If there is not the minimum 6″ overlap, do not use. Contact your dealer to purchase a longer driveline.
Laminated tail wheel
All Tornado RMD rotary cutters are delivered with heady duty laminated tail wheels (Size 4″x8″x15″).
Carbon steel rotor
Heavy duty, hardened carbon steel rotor.
Oval stump jumper
Oval stump jumper protects rotor from impacts. Two heavy duty 1/2″x4″ spring steel blades mounted at the ends of the rotor.
Shafety chains and guards
RMD cutters are equipped standard with front and rear safety chains and rear metal guards.
Side skids
All RMD rotary cutter mower decks are delivered with replaceable side skids.
